Document to Markdown Converter with RAG Chat

Author: Anse Min | 🤗 Hugging Face Space | GitHub | LinkedIn

A powerful Hugging Face Space that converts various document formats to Markdown and enables intelligent chat with your documents using advanced RAG (Retrieval-Augmented Generation).

🎥 Demo Video

▶️ Watch Full Demo (YouTube)

Complete walkthrough of Markit's flagship features including multi-document processing, RAG chat, and advanced retrieval strategies

Table of contents

Demo Video
Live Demos
System Overview
Environment Setup
Local Development
Technical Details

🎬 Live Demos

1. Multi-Document Processing (Flagship Feature)

What it does: Process up to 5 files simultaneously (20MB combined) with 4 intelligent processing types:

🔗 Combined: Merge documents with smart duplicate removal
📑 Individual: Separate sections per document with clear organization
📈 Summary: Executive overview + detailed analysis of all documents
⚖️ Comparison: Cross-document analysis with similarities/differences tables

Why it matters: Industry-leading multi-document processing that compares and contrasts information across different files, handles mixed file types seamlessly, and recognizes relationships across document boundaries.

Industry-leading multi-document processing with 4 intelligent processing types

2. Single Document Conversion Flow

What it does: Convert PDFs, Office documents, images, and more to Markdown using 5 powerful parsers:

Gemini Flash: AI-powered understanding with high accuracy
Mistral OCR: Fastest processing with document understanding
Docling: Open source with advanced PDF table recognition
GOT-OCR: Mathematical/scientific documents to LaTeX
MarkItDown: High accuracy for CSV/XML and broad format support

Why it matters: Perfect table preservation creates enhanced markdown tables for superior RAG context, unlike standard PDF text extraction.

Choose the right parser for your specific needs and document types

3. RAG Chat System in Action

What it does: Chat with your converted documents using 4 advanced retrieval strategies:

🎯 Similarity: Traditional semantic similarity using embeddings
🔀 MMR: Diverse results with reduced redundancy
🔍 BM25: Traditional keyword-based retrieval
🔗 Hybrid: Combines semantic + keyword search (recommended)

Why it matters: Ask for markdown tables in chat responses (impossible with standard PDF RAG), get streaming responses with document context, and easily clear data directly from the interface.

Advanced RAG system with 4 retrieval strategies for optimal document search

4. Query Ranker Analysis

What it does: Interactive document search with:

Real-time ranking of document chunks with confidence scores
Method comparison to test different retrieval strategies
Adjustable results (1-10) with responsive slider control
Transparent scoring with actual ChromaDB similarity scores

Why it matters: Provides complete transparency into how your RAG system finds and ranks information, helping you optimize retrieval strategies.

5. GOT-OCR LaTeX Processing

What it does: Advanced LaTeX processing for mathematical and scientific documents:

Native LaTeX output with no LLM conversion for maximum accuracy
Mathpix rendering using the same library as official GOT-OCR demo
RAG-compatible chunking that preserves LaTeX structures and mathematical tables
Professional display with proper mathematical formatting

Why it matters: Perfect for research papers, scientific documents, and academic content with complex equations and structured data.

🎯 System Overview

Complete workflow from document upload to intelligent RAG chat interaction

🔧 Environment Setup

Required API Keys

GOOGLE_API_KEY=your_gemini_api_key_here    # For Gemini Flash parser and RAG chat
OPENAI_API_KEY=your_openai_api_key_here    # For embeddings and AI descriptions
MISTRAL_API_KEY=your_mistral_api_key_here  # For Mistral OCR parser (optional)

Key Configuration Options

DEBUG=true                        # Enable debug logging
MAX_FILE_SIZE=10485760           # 10MB per file limit
MAX_BATCH_FILES=5                # Maximum files for multi-document processing
MAX_BATCH_SIZE=20971520          # 20MB combined limit for batch processing
CHUNK_SIZE=1000                  # Document chunk size for Markdown content
RETRIEVAL_K=4                    # Number of documents to retrieve for RAG

🚀 Local Development

Quick Start

# Clone repository
git clone https://github.com/ansemin/Markit_v2
cd Markit_v2

# Create environment file
cp .env.example .env
# Edit .env with your API keys

# Install dependencies
pip install -r requirements.txt

# Run application
python app.py                    # Full environment setup (HF Spaces compatible)
python run_app.py               # Local development (faster startup)
python run_app.py --clear-data-and-run  # Testing with clean data

Data Management

Two ways to clear data:

UI Method: Chat tab → "🗑️ Clear All Data" button (works in both local and HF Space)
CLI Method: python run_app.py --clear-data-and-run

What gets cleared: Vector store embeddings, chat history, and session data

🔍 Technical Details

Retrieval Strategy Performance

Method	Best For	Accuracy
🎯 Similarity	General semantic questions	Good
🔀 MMR	Diverse perspectives	Good
🔍 BM25	Exact keyword searches	Medium
🔗 Hybrid	Most queries (recommended)	Excellent

Core Technologies

Parsers: Gemini Flash, Mistral OCR, Docling, GOT-OCR, MarkItDown
RAG System: OpenAI embeddings + ChromaDB vector store + Gemini 2.5 Flash
UI Framework: Gradio with modular component architecture
GPU Support: ZeroGPU integration for HF Spaces

Smart Content-Aware Chunking

Markdown chunking: Preserves tables and code blocks
LaTeX chunking: Preserves mathematical tables, environments, and structures
Automatic format detection: Optimal chunking strategy per document type

Credits

MarkItDown by Microsoft
Docling by IBM Research
GOT-OCR by StepFun
Mathpix Markdown for LaTeX rendering
Gradio for the UI framework

🚀 Try it live on Hugging Face Spaces
