all files

.gitignore

@@ -0,0 +1,4 @@
+__pycache__/
+.DS_Store
+*.pyc
+weights/*

LICENSE

@@ -0,0 +1,21 @@
+MIT License
+
+Copyright (c) 2019 Video Analytics Lab -- IISc
+
+Permission is hereby granted, free of charge, to any person obtaining a copy
+of this software and associated documentation files (the "Software"), to deal
+in the Software without restriction, including without limitation the rights
+to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+copies of the Software, and to permit persons to whom the Software is
+furnished to do so, subject to the following conditions:
+
+The above copyright notice and this permission notice shall be included in all
+copies or substantial portions of the Software.
+
+THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
+AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
+SOFTWARE.

download_from_google.py

@@ -0,0 +1,30 @@
+import requests
+
+def download_file_from_google_drive(id, destination):
+    URL = "https://docs.google.com/uc?export=download"
+
+    session = requests.Session()
+
+    response = session.get(URL, params = { 'id' : id }, stream = True)
+    token = get_confirm_token(response)
+
+    if token:
+        params = { 'id' : id, 'confirm' : token }
+        response = session.get(URL, params = params, stream = True)
+
+    save_response_content(response, destination)
+
+def get_confirm_token(response):
+    for key, value in response.cookies.items():
+        if key.startswith('download_warning'):
+            return value
+
+    return None
+
+def save_response_content(response, destination):
+    CHUNK_SIZE = 32768
+
+    with open(destination, "wb") as f:
+        for chunk in response.iter_content(CHUNK_SIZE):
+            if chunk: # filter out keep-alive new chunks
+                f.write(chunk)

model.py

@@ -0,0 +1,204 @@
+import cv2
+import torch
+import torch.nn as nn
+import numpy as np
+import logging
+from utils_model import compute_boxes_and_sizes, get_upsample_output, get_box_and_dot_maps, get_boxed_img
+from time import time
+
+class LSCCNN(nn.Module):
+    def __init__(self, name='scale_4', checkpoint_path=None, output_downscale=2,
+                 PRED_DOWNSCALE_FACTORS=(8, 4, 2, 1), GAMMA=(1, 1, 2, 4), NUM_BOXES_PER_SCALE=3):
+
+        super(LSCCNN, self).__init__()
+        self.name = name
+        if torch.cuda.is_available():
+            self.rgb_means = torch.cuda.FloatTensor([104.008, 116.669, 122.675])
+        else:
+            self.rgb_means = torch.FloatTensor([104.008, 116.669, 122.675])
+        self.rgb_means = torch.autograd.Variable(self.rgb_means, requires_grad=False).unsqueeze(0).unsqueeze(
+            2).unsqueeze(3)
+
+        self.BOXES, self.BOX_SIZE_BINS = compute_boxes_and_sizes(PRED_DOWNSCALE_FACTORS, GAMMA, NUM_BOXES_PER_SCALE)
+        self.output_downscale = output_downscale
+
+        in_channels = 3
+        self.relu = nn.ReLU(inplace=True)
+        self.conv1_1 = nn.Conv2d(in_channels, 64, kernel_size=3, padding=1)
+        self.conv1_2 = nn.Conv2d(64, 64, kernel_size=3, padding=1)
+        self.pool1 = nn.MaxPool2d(kernel_size=2, stride=2)
+
+        self.conv2_1 = nn.Conv2d(64, 128, kernel_size=3, padding=1)
+        self.conv2_2 = nn.Conv2d(128, 128, kernel_size=3, padding=1)
+        self.pool2 = nn.MaxPool2d(kernel_size=2, stride=2)
+
+        self.conv3_1 = nn.Conv2d(128, 256, kernel_size=3, padding=1)
+        self.conv3_2 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.conv3_3 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.pool3 = nn.MaxPool2d(kernel_size=2, stride=2)
+
+        self.conv4_1 = nn.Conv2d(256, 512, kernel_size=3, padding=1)
+        self.conv4_2 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.conv4_3 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.pool4 = nn.MaxPool2d(kernel_size=2, stride=2)
+
+        self.conv5_1 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.conv5_2 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.conv5_3 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+
+        self.convA_1 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.convA_2 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+        self.convA_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+        self.convA_4 = nn.Conv2d(64, 32, kernel_size=3, padding=1)
+        self.convA_5 = nn.Conv2d(32, 4, kernel_size=3, padding=1)
+
+        self.convB_1 = nn.Conv2d(512, 256, kernel_size=3, padding=1)
+        self.convB_2 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+        self.convB_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+        self.convB_4 = nn.Conv2d(64, 32, kernel_size=3, padding=1)
+        self.convB_5 = nn.Conv2d(32, 4, kernel_size=3, padding=1)
+
+        self.convC_1 = nn.Conv2d(384, 256, kernel_size=3, padding=1)
+        self.convC_2 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+        self.convC_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+        self.convC_4 = nn.Conv2d(64, 32, kernel_size=3, padding=1)
+        self.convC_5 = nn.Conv2d(32, 4, kernel_size=3, padding=1)
+
+        self.convD_1 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.convD_2 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+        self.convD_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+        self.convD_4 = nn.Conv2d(64, 32, kernel_size=3, padding=1)
+        self.convD_5 = nn.Conv2d(32, 4, kernel_size=3, padding=1)
+
+        self.conv_before_transpose_1 = nn.Conv2d(512, 256, kernel_size=3, padding=1)
+        self.transpose_1 = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=2, padding=1, output_padding=1)
+        self.conv_after_transpose_1_1 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+
+        self.transpose_2 = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=2, padding=1, output_padding=1)
+        self.conv_after_transpose_2_1 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+
+        self.transpose_3 = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=4, padding=0, output_padding=1)
+        self.conv_after_transpose_3_1 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+
+        self.transpose_4_1_a = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=4, padding=0, output_padding=1)
+        self.transpose_4_1_b = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=2, padding=1, output_padding=1)
+        self.conv_after_transpose_4_1 = nn.Conv2d(256, 64, kernel_size=3, padding=1)
+
+        self.transpose_4_2 = nn.ConvTranspose2d(256, 256, kernel_size=3, stride=4, padding=0, output_padding=1)
+        self.conv_after_transpose_4_2 = nn.Conv2d(256, 64, kernel_size=3, padding=1)
+
+        self.transpose_4_3 = nn.ConvTranspose2d(128, 128, kernel_size=3, stride=2, padding=1, output_padding=1)
+        self.conv_after_transpose_4_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+
+        self.conv_middle_1 = nn.Conv2d(256, 512, kernel_size=3, padding=1)
+        self.conv_middle_2 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.conv_middle_3 = nn.Conv2d(512, 512, kernel_size=3, padding=1)
+        self.conv_mid_4 = nn.Conv2d(512, 256, kernel_size=3, padding=1)
+
+        self.conv_lowest_1 = nn.Conv2d(128, 256, kernel_size=3, padding=1)
+        self.conv_lowest_2 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.conv_lowest_3 = nn.Conv2d(256, 256, kernel_size=3, padding=1)
+        self.conv_lowest_4 = nn.Conv2d(256, 128, kernel_size=3, padding=1)
+
+        self.conv_scale1_1 = nn.Conv2d(64, 128, kernel_size=3, padding=1)
+        self.conv_scale1_2 = nn.Conv2d(128, 128, kernel_size=3, padding=1)
+        self.conv_scale1_3 = nn.Conv2d(128, 64, kernel_size=3, padding=1)
+
+        if checkpoint_path is not None:
+            self.load_state_dict(torch.load(checkpoint_path))
+
+
+
+    def forward(self, x):
+        mean_sub_input = x
+        mean_sub_input -= self.rgb_means
+
+        #################### Stage 1 ##########################
+
+        main_out_block1 = self.relu(self.conv1_2(self.relu(self.conv1_1(mean_sub_input))))
+        main_out_pool1 = self.pool1(main_out_block1)
+
+        main_out_block2 = self.relu(self.conv2_2(self.relu(self.conv2_1(main_out_pool1))))
+        main_out_pool2 = self.pool2(main_out_block2)
+
+        main_out_block3 = self.relu(self.conv3_3(self.relu(self.conv3_2(self.relu(self.conv3_1(main_out_pool2))))))
+        main_out_pool3 = self.pool3(main_out_block3)
+
+        main_out_block4 = self.relu(self.conv4_3(self.relu(self.conv4_2(self.relu(self.conv4_1(main_out_pool3))))))
+        main_out_pool4 = self.pool3(main_out_block4)
+
+        main_out_block5 = self.relu(self.conv_before_transpose_1(
+            self.relu(self.conv5_3(self.relu(self.conv5_2(self.relu(self.conv5_1(main_out_pool4))))))))
+
+        main_out_rest = self.convA_5(self.relu(
+            self.convA_4(self.relu(self.convA_3(self.relu(self.convA_2(self.relu(self.convA_1(main_out_block5)))))))))
+        if self.name == "scale_1":
+            return main_out_rest
+        ################## Stage 2 ############################
+
+        sub1_out_conv1 = self.relu(self.conv_mid_4(self.relu(
+            self.conv_middle_3(self.relu(self.conv_middle_2(self.relu(self.conv_middle_1(main_out_pool3))))))))
+        sub1_transpose = self.relu(self.transpose_1(main_out_block5))
+        sub1_after_transpose_1 = self.relu(self.conv_after_transpose_1_1(sub1_transpose))
+
+        sub1_concat = torch.cat((sub1_out_conv1, sub1_after_transpose_1), dim=1)
+
+        sub1_out_rest = self.convB_5(self.relu(
+            self.convB_4(self.relu(self.convB_3(self.relu(self.convB_2(self.relu(self.convB_1(sub1_concat)))))))))
+        if self.name == "scale_2":
+            return main_out_rest, sub1_out_rest
+        ################# Stage 3 ############################
+
+        sub2_out_conv1 = self.relu(self.conv_lowest_4(self.relu(
+            self.conv_lowest_3(self.relu(self.conv_lowest_2(self.relu(self.conv_lowest_1(main_out_pool2))))))))
+        sub2_transpose = self.relu(self.transpose_2(sub1_out_conv1))
+        sub2_after_transpose_1 = self.relu(self.conv_after_transpose_2_1(sub2_transpose))
+
+        sub3_transpose = self.relu(self.transpose_3(main_out_block5))
+        sub3_after_transpose_1 = self.relu(self.conv_after_transpose_3_1(sub3_transpose))
+
+        sub2_concat = torch.cat((sub2_out_conv1, sub2_after_transpose_1, sub3_after_transpose_1), dim=1)
+
+        sub2_out_rest = self.convC_5(self.relu(
+            self.convC_4(self.relu(self.convC_3(self.relu(self.convC_2(self.relu(self.convC_1(sub2_concat)))))))))
+
+        if self.name == "scale_3":
+            return main_out_rest, sub1_out_rest, sub2_out_rest
+        ################# Stage 4 ############################
+        sub4_out_conv1 = self.relu(
+            self.conv_scale1_3(self.relu(self.conv_scale1_2(self.relu(self.conv_scale1_1(main_out_pool1))))))
+
+        # TDF 1
+        tdf_4_1_a = self.relu(self.transpose_4_1_a(main_out_block5))
+        tdf_4_1_b = self.relu(self.transpose_4_1_b(tdf_4_1_a))
+        after_tdf_4_1 = self.relu(self.conv_after_transpose_4_1(tdf_4_1_b))
+
+        # TDF 2
+        tdf_4_2 = self.relu(self.transpose_4_2(sub1_out_conv1))
+        after_tdf_4_2 = self.relu(self.conv_after_transpose_4_2(tdf_4_2))
+
+        # TDF 3
+        tdf_4_3 = self.relu(self.transpose_4_3(sub2_out_conv1))
+        after_tdf_4_3 = self.relu(self.conv_after_transpose_4_3(tdf_4_3))
+
+        sub4_concat = torch.cat((sub4_out_conv1, after_tdf_4_1, after_tdf_4_2, after_tdf_4_3), dim=1)
+        sub4_out_rest = self.convD_5(self.relu(
+            self.convD_4(self.relu(self.convD_3(self.relu(self.convD_2(self.relu(self.convD_1(sub4_concat)))))))))
+
+        logging.info("Forward Finished")
+        if self.name == "scale_4":
+            return main_out_rest, sub1_out_rest, sub2_out_rest, sub4_out_rest
+
+
+    def predict_single_image(self, image, emoji, nms_thresh=0.25, thickness=2, multi_colours=True):
+        if image.shape[0] % 16 or image.shape[1] % 16:
+            image = cv2.resize(image, (image.shape[1]//16*16, image.shape[0]//16*16))
+        img_tensor = torch.from_numpy(image.transpose((2, 0, 1)).astype(np.float32)).unsqueeze(0)
+        with torch.no_grad():
+            out = self.forward(img_tensor.cuda())
+            # out = self.forward(img_tensor)
+        out = get_upsample_output(out, self.output_downscale)
+        pred_dot_map, pred_box_map = get_box_and_dot_maps(out, nms_thresh, self.BOXES)
+        img_out = get_boxed_img(image, emoji, pred_box_map, pred_box_map, pred_dot_map, self.output_downscale,
+                                self.BOXES, self.BOX_SIZE_BINS, thickness=thickness, multi_colours=multi_colours)
+        return pred_dot_map, pred_box_map, img_out

requirements.txt

@@ -0,0 +1 @@
+opencv-python==4.4.0.40

run-gradio.py

@@ -0,0 +1,43 @@
+import cv2
+from model import LSCCNN
+from download_from_google import download_file_from_google_drive
+import os
+import gradio as gr
+from time import time
+if not os.path.exists("weights/weights.pth"):
+    os.mkdir("weights")
+    output = 'weights/weights.pth'
+    file_id = '1QbPwRXcrONMuBL_39gvnvGGsFCnNyjEm'
+    download_file_from_google_drive(file_id, output)
+
+
+checkpoint_path = './weights/weights.pth'
+network = LSCCNN(checkpoint_path=checkpoint_path)
+network.cuda()
+network.eval()
+emoji = cv2.imread("images/blm_fist.png", -1)
+
+
+def predict(img):
+    if img.shape[2] > 3:
+        img = img[:, :, :3]
+    pred_dot_map, pred_box_map, img_out = \
+        network.predict_single_image(img, emoji, nms_thresh=0.25)
+    return img_out
+
+thumbnail="https://i.ibb.co/bzwSBzw/Screen-Shot-2020-08-24-at-7-05-36-AM.png"
+examples=[
+    ["images/1.png"],
+    ["images/2.png"],
+    ["images/3.png"],
+    ["images/4.png"],
+    ["images/5.png"]
+]
+
+gr.Interface(predict, "image", "image", title="BLM Photo "
+                                              "Anonymization",
+             description="Anonymize photos to protect BLM "
+                         "protesters. Faces will be covered with the "
+                         "black fist emoji. Model developed by the Stanford ML Group and LSC-CNN.", examples=examples,
+             thumbnail=thumbnail).launch()
+

utils_model.py

@@ -0,0 +1,174 @@
+from utils_nms import apply_nms
+from PIL import Image
+import cv2
+import torch
+import numpy as np
+import copy
+import logging
+
+
+def compute_boxes_and_sizes(PRED_DOWNSCALE_FACTORS, GAMMA,
+                            NUM_BOXES_PER_SCALE):
+    BOX_SIZE_BINS = [1]
+    g_idx = 0
+    while len(BOX_SIZE_BINS) < NUM_BOXES_PER_SCALE * len(
+            PRED_DOWNSCALE_FACTORS):
+        gamma_idx = len(BOX_SIZE_BINS) // (len(GAMMA) - 1)
+        box_size = BOX_SIZE_BINS[g_idx] + GAMMA[gamma_idx]
+        BOX_SIZE_BINS.append(box_size)
+        g_idx += 1
+
+    BOX_SIZE_BINS_NPY = np.array(BOX_SIZE_BINS)
+    BOXES = np.reshape(BOX_SIZE_BINS_NPY, (4, 3))
+    BOXES = BOXES[::-1]
+
+    return BOXES, BOX_SIZE_BINS
+
+
+def upsample_single(input_, factor=2):
+    channels = input_.size(1)
+    indices = torch.nonzero(input_)
+    indices_up = indices.clone()
+    # Corner case!
+    if indices_up.size(0) == 0:
+        return torch.zeros(input_.size(0),input_.size(1), input_.size(2)*factor, input_.size(3)*factor).cuda()
+        # return torch.zeros(input_.size(0), input_.size(1),
+        #                    input_.size(2) * factor, input_.size(3) * factor)
+    indices_up[:, 2] *= factor
+    indices_up[:, 3] *= factor
+
+    output = torch.zeros(input_.size(0),input_.size(1), input_.size(2)*factor, input_.size(3)*factor).cuda()
+    # output = torch.zeros(input_.size(0), input_.size(1),
+    #                      input_.size(2) * factor, input_.size(3) * factor)
+    output[indices_up[:, 0], indices_up[:, 1], indices_up[:, 2], indices_up[:,
+                                                                 3]] = input_[
+        indices[:, 0], indices[:, 1], indices[:, 2], indices[:, 3]]
+
+    output[indices_up[:, 0], channels - 1, indices_up[:, 2] + 1, indices_up[:,
+                                                                 3]] = 1.0
+    output[indices_up[:, 0], channels - 1, indices_up[:, 2], indices_up[:,
+                                                             3] + 1] = 1.0
+    output[indices_up[:, 0], channels - 1, indices_up[:, 2] + 1, indices_up[:,
+                                                                 3] + 1] = 1.0
+
+    # output_check = nn.functional.max_pool2d(output, kernel_size=2)
+
+    return output
+
+
+def get_upsample_output(model_output, output_downscale):
+    upsample_max = int(np.log2(16 // output_downscale))
+    upsample_pred = []
+    for idx, out in enumerate(model_output):
+        out = torch.nn.functional.softmax(out, dim=1)
+        upsample_out = out
+        for n in range(upsample_max - idx):
+            upsample_out = upsample_single(upsample_out, factor=2)
+        upsample_pred.append(upsample_out.cpu().data.numpy().squeeze(0))
+    return upsample_pred
+
+
+def box_NMS(predictions, nms_thresh, BOXES):
+    Scores = []
+    Boxes = []
+    for k in range(len(BOXES)):
+        scores = np.max(predictions[k], axis=0)
+        boxes = np.argmax(predictions[k], axis=0)
+        # index the boxes with BOXES to get h_map and w_map (both are the same for us)
+        mask = (boxes < 3)  # removing Z
+        boxes = (boxes + 1) * mask
+        scores = (
+                    scores * mask)  # + 100 # added 100 since we take logsoftmax and it's negative!!
+
+        boxes = (boxes == 1) * BOXES[k][0] + (boxes == 2) * BOXES[k][1] + (
+                    boxes == 3) * BOXES[k][2]
+        Scores.append(scores)
+        Boxes.append(boxes)
+
+    x, y, h, w, scores = apply_nms(Scores, Boxes, Boxes, 0.5,
+                                   thresh=nms_thresh)
+
+    nms_out = np.zeros((predictions[0].shape[1], predictions[0].shape[
+        2]))  # since predictions[0] is of size 4 x H x W
+    box_out = np.zeros((predictions[0].shape[1], predictions[0].shape[
+        2]))  # since predictions[0] is of size 4 x H x W
+    for (xx, yy, hh) in zip(x, y, h):
+        nms_out[yy, xx] = 1
+        box_out[yy, xx] = hh
+
+    assert (np.count_nonzero(nms_out) == len(x))
+
+    return nms_out, box_out
+
+
+def get_box_and_dot_maps(pred, nms_thresh, BOXES):
+    assert (len(pred) == 4)
+    # NMS on the multi-scale outputs
+    nms_out, h = box_NMS(pred, nms_thresh, BOXES)
+    return nms_out, h
+
+
+def get_boxed_img(image, original_emoji, h_map, w_map, gt_pred_map,
+                  prediction_downscale, BOXES, BOX_SIZE_BINS,
+                  thickness=1, multi_colours=False):
+    if image.shape[2] != 3:
+        boxed_img = image.astype(np.uint8).transpose((1, 2, 0)).copy()
+    else:
+        boxed_img = image.astype(np.uint8).copy()
+    head_idx = np.where(gt_pred_map > 0)
+
+    H, W = boxed_img.shape[:2]
+
+    Y, X = head_idx[-2], head_idx[-1]
+
+    # scale to image
+    enlarge_factor = max(((H * W) / (48 ** 2)) // 300, 1)
+
+    for i, (y, x) in enumerate(zip(Y, X)):
+
+        h, w = h_map[y, x] * prediction_downscale, w_map[
+            y, x] * prediction_downscale
+        scale = ((BOX_SIZE_BINS.index(h // prediction_downscale)) // 3) + 1
+
+        if enlarge_factor > 1:
+            h *= enlarge_factor / 2
+            w *= enlarge_factor / 2
+
+        expand_w = (0.2 * scale * w) // 2
+        expand_h = (0.2 * scale * h) // 2
+
+        y2 = min(int((prediction_downscale * x + w / 2) + expand_w), W)
+        y1 = max(int((prediction_downscale * x - w / 2) - expand_w), 0)
+        x2 = min(int((prediction_downscale * y + h / 2) + expand_h), H)
+        x1 = max(int((prediction_downscale * y - h / 2) - expand_h), 0)
+
+        emoji = copy.deepcopy(original_emoji)
+        # emoji = original_emoji.copy()
+        width = x2 - x1
+        height = y2 - y1
+        emoji = cv2.resize(emoji, (height, width))
+        # emoji = emoji.resize((width, height))
+        # emoji = np.array(emoji)
+
+        # https://gist.github.com/clungzta/b4bbb3e2aa0490b0cfcbc042184b0b4e
+
+        # Extract the alpha mask of the RGBA image, convert to RGB
+        r, g, b, a = cv2.split(emoji)
+        overlay_color = cv2.merge((b, g, r))
+
+        # Apply some simple filtering to remove edge noise
+        mask = cv2.medianBlur(a, 5)
+        mask[mask != 255] = 0
+        roi = boxed_img[x1:x2, y1:y2]
+
+        # Black-out the area behind the emoji in our original ROI
+        img1_bg = cv2.bitwise_and(roi.copy(), roi.copy(),
+                                  mask=cv2.bitwise_not(mask))
+
+        # Mask out the emoji from the emoji image.
+        img2_fg = cv2.bitwise_and(overlay_color, overlay_color, mask=mask)
+
+        # Update the original image with our new ROI
+        boxed_img[x1:x2, y1:y2] = cv2.add(img1_bg, img2_fg)
+
+    return boxed_img

utils_nms.py

@@ -0,0 +1,152 @@
+"""
+apply_nms.py: Wrapper for nms.py
+Authors : svp
+"""
+
+import numpy as np
+
+'''
+	nms.py: CPU implementation of non maximal supression modified from Ross's code.
+	Authors : svp
+
+	Modified from https://github.com/rbgirshick/fast-rcnn/blob/master/lib/utils/nms.py
+	to accommodate a corner case which handles one box lying completely inside another.
+'''
+
+
+def nms(dets, thresh):
+    x1 = dets[:, 0]
+    y1 = dets[:, 1]
+    x2 = dets[:, 2]
+    y2 = dets[:, 3]
+    scores = dets[:, 4]
+
+    areas = (x2 - x1 + 1) * (y2 - y1 + 1)
+
+    order = scores.argsort()[::-1]
+
+    keep = []
+    while order.size > 0:
+        i = order[0]
+        keep.append(i)
+        xx1 = np.maximum(x1[i], x1[order[1:]])
+        yy1 = np.maximum(y1[i], y1[order[1:]])
+        xx2 = np.minimum(x2[i], x2[order[1:]])
+        yy2 = np.minimum(y2[i], y2[order[1:]])
+
+        w = np.maximum(0.0, xx2 - xx1 + 1)
+        h = np.maximum(0.0, yy2 - yy1 + 1)
+        inter = w * h
+        remove_index_1 = np.where(areas[i] == inter)
+        remove_index_2 = np.where(areas[order[1:]] == inter)
+        ovr = inter / (areas[i] + areas[order[1:]] - inter)
+        ovr[remove_index_1] = 1.0
+        ovr[remove_index_2] = 1.0
+        inds = np.where(ovr <= thresh)[0]
+        order = order[inds + 1]
+
+    return keep
+
+
+'''
+    Extracts confidence map and box map from N (N=4 here)
+	channel input.
+
+    Parameters:
+    -----------
+    confidence_map - (list) list of confidences for N channels
+    hmap - (list) list of box values for N channels
+
+    Returns
+    -------
+    nms_conf_map - (HXW) single channel confidence score map
+	nms_conf_box - (HXW) single channel box map.
+'''
+
+
+def extract_conf_points(confidence_map, hmap):
+    nms_conf_map = np.zeros_like(confidence_map[0])
+    nms_conf_box = np.zeros_like(confidence_map[0])
+
+    idx_1 = np.where(np.logical_and(confidence_map[0] > 0, confidence_map[1] <= 0))
+    idx_2 = np.where(np.logical_and(confidence_map[0] <= 0, confidence_map[1] > 0))
+    idx_common = np.where(np.logical_and(confidence_map[0] > 0, confidence_map[1] > 0))
+
+    nms_conf_map[idx_1] = confidence_map[0][idx_1]
+    nms_conf_map[idx_2] = confidence_map[1][idx_2]
+
+    nms_conf_box[idx_1] = hmap[0][idx_1]
+    nms_conf_box[idx_2] = hmap[1][idx_2]
+
+    for ii in range(len(idx_common[0])):
+        x, y = idx_common[0][ii], idx_common[1][ii]
+        if confidence_map[0][x, y] > confidence_map[1][x, y]:
+            nms_conf_map[x, y] = confidence_map[0][x, y]
+            nms_conf_box[x, y] = hmap[0][x, y]
+        else:
+            nms_conf_map[x, y] = confidence_map[1][x, y]
+            nms_conf_box[x, y] = hmap[1][x, y]
+
+    assert (np.sum(nms_conf_map > 0) == len(idx_1[0]) + len(idx_2[0]) + len(idx_common[0]))
+
+    return nms_conf_map, nms_conf_box
+
+
+'''
+    Wrapper function to perform NMS
+
+    Parameters:
+    -----------
+    confidence_map - (list) list of confidences for N channels
+    hmap - (list) list of box values for N channels
+    wmap - (list) list of box values for N channels
+    dotmap_pred_downscale -(int) prediction scale
+    thresh - (float) Threshold for NMS.
+
+    Returns
+    -------
+    x, y - (list) list of x-coordinates and y-coordinates to keep
+           after NMS.
+    h, w - (list) list of height and width of the corresponding x, y
+            points.
+    scores - (list) list of confidence for h and w at (x, y) point.
+
+'''
+
+
+def apply_nms(confidence_map, hmap, wmap, dotmap_pred_downscale=2, thresh=0.3):
+    nms_conf_map, nms_conf_box = extract_conf_points([confidence_map[0], confidence_map[1]], [hmap[0], hmap[1]])
+    nms_conf_map, nms_conf_box = extract_conf_points([confidence_map[2], nms_conf_map], [hmap[2], nms_conf_box])
+    nms_conf_map, nms_conf_box = extract_conf_points([confidence_map[3], nms_conf_map], [hmap[3], nms_conf_box])
+
+    confidence_map = nms_conf_map
+    hmap = nms_conf_box
+    wmap = nms_conf_box
+
+    confidence_map = np.squeeze(confidence_map)
+    hmap = np.squeeze(hmap)
+    wmap = np.squeeze(wmap)
+
+    dets_idx = np.where(confidence_map > 0)
+
+    y, x = dets_idx[-2], dets_idx[-1]
+    h, w = hmap[dets_idx], wmap[dets_idx]
+    x1 = x - w / 2
+    x2 = x + w / 2
+    y1 = y - h / 2
+    y2 = y + h / 2
+    scores = confidence_map[dets_idx]
+
+    dets = np.stack([np.array(x1), np.array(y1), np.array(x2), np.array(y2), np.array(scores)], axis=1)
+    # List of indices to keep
+    keep = nms(dets, thresh)
+
+    y, x = dets_idx[-2], dets_idx[-1]
+    h, w = hmap[dets_idx], wmap[dets_idx]
+    x = x[keep]
+    y = y[keep]
+    h = h[keep]
+    w = w[keep]
+
+    scores = scores[keep]
+    return x, y, h, w, scores
